Product Name：主機箱蓋

Material[材料]：PP+30%LGF

Part Weight[克重]：1.63kg

Cavity Qty[模穴]：1

System Type[系統類型]：針閥式熱流道系統

Color[顏色]：黑色

Description 說明：

      主機箱蓋，材料PP+30%LGF，壁厚3.0mm。由于材料加了長玻纖，在熱流道注塑時要特別注意流道的走向及其轉角處的處理。為此占瑞選擇針閥式熱流道系統，在制品上不會留下進澆口殘痕，進澆口處痕跡平滑；為了使長玻纖不會斷裂，占瑞特別設計了一款熱流道鑲件，讓注塑更完美。

Main Box Cover, material is PP + 30% LGF.

The wall thickness is 3.0mm.

Due to the addition of long glass fiber in the material, special attention should be paid to the flow direction and the hot runner treatment during injection molding. So, ANRY choose valve type hot runner system, which will not leave any residual mark on the product, and the gate mark is smooth.

In order to prevent the long glass fiber from breaking, ANRY specially designed a hot runner insert to make the injection molding more perfect.
